For the construction drawing of a project, this is very important. It plays a role that we can’t underestimate. Our project should operate according to the above drawings, and the steel structure is the same. What should the design principles of the steel structure construction drawing follow?Let’s take a look at HJSD steel structure engineering company.

   1.It must be based on the design drawing of steel structure, and follow the current code for design of steel structure, code for construction and acceptance of steel structure engineering and other relevant codes, regulations and standards.If possible, CAD method should be used for design as much as possible.

   2.The design requires that the node standardization, component standardization, hole spacing and hole diameter should be unified as far as possible to reduce the number of components and parts; at the same time, the feasibility of construction technology should be considered to meet the possibility of continuous production and combined hoisting of steel structure.

   3.The joint structure should be simplified, reasonable, safe, reliable and convenient for fabrication and installation.

   4.Factory production should be adopted as far as possible to reduce manual operation and installation workload, which is economical and reasonable.Advanced technology, safe and applicable, to speed up the construction speed and ensure the quality of the project.

   5.The factory unit and component number of components shall be determined according to the manufacturing, installation and transportation conditions.The maximum outline size of components shall meet the requirements of limit transportation size of highway, railway or water transportation, and the weight of components shall also meet the lifting and transportation capacity.
